| Nguồn gốc: | Trung Quốc |
| Hàng hiệu: | RJ |
| Chứng nhận: | CE/ROSE |
| Số mô hình: | RJ |
| Model | RJ |
| Capacity | 300g, 500g,750g, 1kg, 2kg, 3kg |
| Comprehensive Error | 0.05 % F.S |
| Output sensitivity | 300g: 0.7±0.15MV/V , 500g-750g: 0.8±0.15 MV/V, 1kg-3kg: 1.0±0.15 MV/V |
| Non-linearity | 0.05 (%F.S.) |
| Repeatability | 0.05 (%F.S.) |
| Hysteresis | 0.05 (%F.S.) |
| Creep | 0.1 [(3 min)%F.S.] |
| Zero Output | ± 0.1 m V/V |
| Temp. Effect on Zero | 0.2(%F.S/10℃) |
| Temp. Effect on Span | 0.05(%F.S 10℃) |
| Input Resistance | 1000 ± 10 Ω |
| Output Resistance | 1050 ± 100 Ω |
| Insulation Resistance | ≥ 2000 MΩ |
| Excitation Voltage | 3~10Vdc |
| Operating Temperature range | -10~+40℃ |
| Four corner error | ± 0.1% F.S |
| Safe overload | 120% F.S |
| Ultimate Overload | 150% F.S |
| Cable length | Φ0.6 x 110 mm |
| Wiring | Excitation +: Red, Excitation-: Black Signal+: Green, Signal- : White |
| Application | Jewelry scale, small weight scale, kitchen scale, force test |
